WebApi接口采集指标数据的配置实践操作(组图)

)

　　

　　这个文章的主要目的是告诉你如何配置Prometheus，使其可以使用指定的Web Api接口采集指标数据。文章中使用的case是NGINX的采集配置，来自NGINX数据索引页的采集数据，设置了用户名和密码，所以这是文章@的副标题> 可能是nginx的prometheus 采集配置或者prometheus 采集 basic auth的nginx。

　　

　　上图展示了配置完成后在Grafana中配置模板的效果。

　　用过Prometheus的朋友一定知道如何配置address:port服务。比如在采集某个Redis的信息时，配置可以这样写：

　　 - job_name: 'redis'

static_configs:

- targets: ['11.22.33.58:6087']

复制代码

　　注意：以上情况假设Redis Exporter的地址和端口为11.22.33.58:6087。

　　这是最简单也是最广为人知的方法。但是如果要监控指定的Web API，就不能这样写了。如果你没有看到这个 文章，你可能会在搜索引擎中搜索这样的：

　　但是很遗憾，没有找到有效的信息（现在是2021年3月），基本上所有的坑都能找到。

　　条件假设

　　假设我们现在需要从带有地址...的接口采集相关的Prometheus监控指标，并且该接口使用basic auth（假设用户名为weishidong，密码为0099887kk）进行基本授权验证。

　　配置实践

　　如果填写之前看到的Prometheus配置，很可能这样写配置：

　　 - job_name: 'web'

static_configs:

- targets: ['http://www.weishidong.com/status/format/prometheus']

basic_auth:

username: weishidong

password: 0099887kk

复制代码

　　保存配置文件，重启服务后，你会发现这种方式无法采集数据，太可怕了。

　　官方配置指南

　　刚才的*敏*感*词*实在是太可怕了。当我们遇到不明白的问题时，我们当然去官方文档-> Prometheus Configuration。建议从上到下阅读，但如果你赶时间，可以直接来这部分。官方示例如下（内容太多，这里只保留与本文相关的部分，建议大家阅读原文）：

　　# The job name assigned to scraped metrics by default.

job_name:

# How frequently to scrape targets from this job.

[ scrape_interval: | default = ]

# Per-scrape timeout when scraping this job.

[ scrape_timeout: | default = ]

# The HTTP resource path on which to fetch metrics from targets.

[ metrics_path: | default = /metrics ]

# honor_labels controls how Prometheus handles conflicts between labels that are

# already present in scraped data and labels that Prometheus would attach

# server-side ("job" and "instance" labels, manually configured target

# labels, and labels generated by service discovery implementations).

#

# If honor_labels is set to "true", label conflicts are resolved by keeping label

# values from the scraped data and ignoring the conflicting server-side labels.

#

# If honor_labels is set to "false", label conflicts are resolved by renaming

# conflicting labels in the scraped data to "exported_" (for

# example "exported_instance", "exported_job") and then attaching server-side

# labels.

#

# Setting honor_labels to "true" is useful for use cases such as federation and

# scraping the Pushgateway, where all labels specified in the target should be

# preserved.

#

# Note that any globally configured "external_labels" are unaffected by this

# setting. In communication with external systems, they are always applied only

# when a time series does not have a given label yet and are ignored otherwise.

[ honor_labels: | default = false ]

# honor_timestamps controls whether Prometheus respects the timestamps present

# in scraped data.

#

# If honor_timestamps is set to "true", the timestamps of the metrics exposed

# by the target will be used.

#

# If honor_timestamps is set to "false", the timestamps of the metrics exposed

# by the target will be ignored.

[ honor_timestamps: | default = true ]

# Configures the protocol scheme used for requests.

[ scheme: | default = http ]

# Optional HTTP URL parameters.

params:

[ : [, ...] ]

# Sets the `Authorization` header on every scrape request with the

# configured username and password.

# password and password_file are mutually exclusive.

basic_auth:

[ username: ]

[ password: ]

[ password_file: ]

# Sets the `Authorization` header on every scrape request with

# the configured bearer token. It is mutually exclusive with `bearer_token_file`.

[ bearer_token: ]

# Sets the `Authorization` header on every scrape request with the bearer token

# read from the configured file. It is mutually exclusive with `bearer_token`.

[ bearer_token_file: ]

复制代码

　　如果仔细看，应该注意几个关键信息：metrics_path 和 basic_auth。其中，metrics_path用于指定HTTP类型指示符信息采集时的路由地址，默认值为/metrics；字段basic_auth用于授权验证，这里的password可以指定一个密码文件，而不是直接填写明文（一般来说，指定的密码文件的安全性稍高，明文）。

　　有效配置

　　根据官方文档的指引，我们可以快速推导出正确的配置写法：

　　- job_name: 'web'

metrics_path: /status/format/prometheus

static_configs:

- targets: ['www.weishidong.com']

basic_auth:

username: weishidong

password: 0099887kk

复制代码

　　需要注意的是这里的字不用填，因为Prometheus默认的Scheme是http。如果地址的scheme是https，我们需要根据文档指引添加scheme字段，对应的配置为：

　　- job_name: 'web'

metrics_path: /status/format/prometheus

static_configs:

- targets: ['www.weishidong.com']

scheme: https

basic_auth:

username: weishidong

password: 0099887kk

复制代码

　　配置完成后，Prometheus应该可以成功采集获取数据。用Grafana，可以看到开头给出的监控效果图。
