　　写在前面

　　ELK 三剑客（ElasticSearch、Logstash、Kibana）基本可以满足一些日志采集

、信息处理、统计分析、可视化报表等日志分析任务，但是对我们来说……太重了，技术栈也不是全部道路。我们的场景是在各个业务部门的服务器上采集各种业务系统，所以尽量不影响服务器的性能，以侵入性最小的方式采集，不做其他冗余操作。因此，在前端日志采集方面，与Logstash、Flume等其他采集工具进行对比后，决定使用轻量级的**Filebeat**作为日志采集工具。Filebeat 由 Go 开发，运行不需要额外的部署环境，更依赖 Flume。

　　采集链接如下： Filebeat日志采集、处理、转换后推送到kafka，使用clickhouse的kafka引擎进行消费和存储。因此，我暂时将其称为肯德基组合。

　　

　　Filebeat 部署

　　采集目标环境：

　　系统：Window Server 2008 R2 Enterprise

　　日志类别：IIS日志、业务系统日志

　　日志路径：D:/IIS//logs/.txt, D:/IIS//logs/.txt, D:/IIS//logs/*.txt

　　文件节拍：7.12.1 ()

　　

　　由于合集是windows操作系统，建议下载Filebeat压缩包，作为windows服务运行。安装包msi不方便调试，需要频繁的卸载安装操作。下载后解压，在配置文件filebeat.yml中进行配置。

　　业务系统日志格式示例：

　　2021-04-06 11:21:17,940 [39680] DEBUG Zc - time:0ms update XXX set ModifyTime=GETDATE(), [State] = 190, [FuZeRen] = '张三' where [ID] = '90aa9a69-7a33-420e-808c-624693c65aef' and [CompanyID] = '9e52867e-2035-4148-b09e-55a90b3020d5'

2021-04-06 11:21:21,612 [22128] DEBUG Service ModelBase - time:0ms (/api/XXX/XXX/XXX?InfoID=6d43b831-6169-46d2-9518-f7c9ed6fe39c&ValidateStatus=1)更新材料状态

2021-04-06 11:21:21,612 [22128] DEBUG Zc - time:0ms select ID from XXX where InfoRelationID='6d43b831-6169-46d2-9518-f7c9ed6fe39c'

2021-04-06 11:21:21,612 [22128] DEBUG Zc - time:0ms insert into XXXX(ValidateDate ,[ID],[ValidateState],[ValidateUser],[ValidateUserID],[ValidateUnit],[ValidateUnitID],[ValidateUnitType],[InfoRelationID]) values( GETDATE(),'c77cf4ab-71b5-46c7-b91b-2829d73aa700',1,'XXXX','0387f889-e1d4-48aa-b275-2241da1d2c9e','XXXXX*敏*感*词*','2f2a94c8-c23c-4e8a-98b3-c32a9b0487f7',0,'6d43b831-6119-46d2-9518-f7c9ed6fe39c')

2021-04-06 03:25:22,237 [46840] ERROR ASP.global_asax - time:0ms 客户端信息：Ip:116.238.55.21, 173.131.245.61 浏览器:Chrome 版本:68 操作系统:WinNT服务端错误信息：

页面：http://www.A.com:803/dbapp_53475dbapp_e524534.php

错误源：System.Web.Mvc

堆栈跟踪： at System.Web.Mvc.DefaultControllerFactory.GetControllerInstance(RequestContext requestContext, Type controllerType)

at System.Web.Mvc.DefaultControllerFactory.CreateController(RequestContext requestContext, String controllerName)

at System.Web.Mvc.MvcHandler.ProcessRequestInit(HttpContextBase httpContext, IController& controller, IControllerFactory& factory)

at System.Web.Mvc.MvcHandler.BeginProcessRequest(HttpContextBase httpContext, AsyncCallback callback, Object state)

at System.Web.HttpApplication.CallHandlerExecutionStep.System.Web.HttpApplication.IExecutionStep.Execute()

at System.Web.HttpApplication.ExecuteStep(IExecutionStep step, Boolean& completedSynchronously)

　　FileBeat 配置：

<p>max_procs: 2

queue:

mem:

events: 2048

flush.min_events: 2048

# ============================== Filebeat inputs ===============================

filebeat.inputs:

# 管理系统

- type: log

enabled: true

encoding: GB2312

paths:

- D:/IIS/www.A.com/logs/*.txt

multiline.pattern: &#39;^\d{4}-\d{1,2}-\d{1,2}&#39;

multiline.negate: true

multiline.match: after

fields:

topic: &#39;dlbZcZGBSyslogs&#39;

fields_under_root: true

# 单位系统

- type: log

enabled: true

encoding: GB2312

paths:

- D:/IIS/www.B.com/logs/*.txt

### Multiline options

multiline.pattern: &#39;^\d{4}-\d{1,2}-\d{1,2}&#39;

multiline.negate: true

multiline.match: after

fields:

topic: &#39;dlbZcDWSyslogs&#39;

fields_under_root: true

# 个人系统

- type: log

enabled: true

encoding: GB2312

paths:

- D:/IIS/www.C.com/logs/*.txt

### Multiline options

multiline.pattern: &#39;^\d{4}-\d{1,2}-\d{1,2}&#39;

multiline.negate: true

multiline.match: after

fields:

topic: &#39;dlbZcMySyslogs&#39;

fields_under_root: true

# 调试输出

#output.console:

# pretty: true

#output.file:

# path: "D:/bigData"

# filename: filebeat.log

# -------------------------------- Kafka Output --------------------------------

output.kafka:

# Boolean flag to enable or disable the output module.

enabled: true

hosts: ["192.168.1.10:9092"]

# The Kafka topic used for produced events. The setting can be a format string

# using any event field. To set the topic from document type use `%{[type]}`.

topic: &#39;%{[topic]}&#39;

# Authentication details. Password is required if username is set.

#username: &#39;&#39;

#password: &#39;&#39;

# The number of concurrent load-balanced Kafka output workers.

worker: 2

max_message_bytes: 10000000

# ================================= Processors =================================

processors:

- add_host_metadata:

when.not.contains.tags: forwarded

- add_cloud_metadata: ~

- add_docker_metadata: ~

- add_kubernetes_metadata: ~

- script:

lang: javascript

id: my_filter

tag: enable

source: >

function process(event) {

var str = event.Get("message");

var sp = str.split(" ");

var log_datetime = sp.slice(0,2).join(" ");

var regEx = /^\d{4}-\d{2}-\d{2}$/;

var prefix_date = log_datetime.substring(0, 10);

if(prefix_date.match(regEx) != null)

{

event.Put("server","221");

log_datetime = log_datetime.replace(",",".");

log_datetime = log_datetime.replace("&#39;","");

regEx = /^\d{4}-\d{2}-\d{2}\s\d{2}:\d{2}:\d{2}.\d{3}$/;

if(log_datetime.match(regEx) != null)

{

event.Put("log_datetime",log_datetime);

event.Put("log_index",sp.slice(2,3).join(" ").replace("[","").replace("]",""));

event.Put("log_level",sp.slice(3,4).join(" "));

if(str.match(/(?
